Colours

M 01 2023 0166
M 01 2023 0162
M 01 2023 0155
M 01 2022 1115
M 01 2023 0156
M 01 2023 0158
M 01 2023 0159
M 01 2023 0164
M 01 2023 0165
M 01 2023 0163
M 01 2023 0157
M 01 2022 1116
M 01 2023 0154
M 01 2023 0153
M 01 2023 0161
M 01 2023 0160

Classic Weaves

Diamond Check

Diamond Check, an elevated checked pattern derived from the established tartan pattern that holds a significant place throughout fashion and history.

Type:: Woven Carpet
Width:: 3.66m
Colours:: 16 colours

Product Specifications
Collection:
Classic Weaves
Colours:
16 Standard
Yarn:
80% Wool / 20% Synthetic
Product Thickness:
10mm
Pile Weight:
1290g/m²
Backing:
Polypropylene Weft
Installation Method:
Dual Bond Recommended
Notes:
Available in 4 qualities - 34oz, 38oz 42oz and 48oz. Fast Track® minimum order quantity applies = 20lm (73m2)
Type:
Woven Carpet
Roll Width:
3.66m
Pattern Repeat:
Width: 30.48cm Length: 30.48cm (Set Match)
Pitch & Beat Up:
Pitch: 27.6/10 (7/inch) Beat Up: 31.5/10cm (8/inch)
Performance
Anti-Static:
(AATCC 134) <3.5KV at 21°C & 20% Relative Humidity
Flammability:
CRF 4.5kW/m² (Dual Bond)#
Colourfast to light:
(ISO 105-B-02-1994) 5-6
Light Reflectance:
Available on Request
Stain Resistance:
Natural Wool Fibre Stain Resistance
ACCS Rating:
Contract Heavy Duty - 3 Star
Contract Warranty:
7 Year Contract Guarantee Available on Request*
Smoke Value:
750% minutes (Dual Bond)
Recommended Adhesive:
Refer to our GH Commercial Adhesive Guide www.ghcommercial.com
Sustainability
PVC Minimisation:
PVC Free
Indoor Air Quality:
Green Building Council compliant for VOC emission rate limits
Green Star:
Environmental Certification Scheme (ECS). Level 4 Maximum Points - Certificate
Accreditation:
Manufactured under a quality and environmental system certified and complying with ISO 9001 and ISO 14001 by an accredited certification body.
Documents

Download Product Spec Sheet
